DESCRIPTION
×Add a contemporary look to your kitchen with this black stainless wall mount kitchen hood featuring bright, long-lasting LED task lighting. You'll have the right amount of ventilation for all of your cooking thanks to the 3-speed, 400 CFM motor class. A grease filter helps traps unwanted grease and odors. And depending on your kitchen ventilation system setup, you can vent vapors and odors outside or filter them and recirculate the air thanks to the range hood's convertible ventilation. When venting at low speed, sound levels can get as low as 44 dBA.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Blower Included
Yes
Airflow
400 CFM
Style
Chimney
Color
Black Stainless
Manufacturer Color
Black stainless steel
Installation
Wall Mount
Features
Wi-Fi
No
Dishwasher-Proof Filters
Yes
Ducting Information
6-inch round
Speeds
3-speed
Additional Information
• LED task lighting
• 44 dBA (.7 Sones) at low speed
• 69 dBA (5.6 sones) at max speed
• Convertible ventilation (recirculating or vented)
• 44 dBA (.7 Sones) at low speed
• 69 dBA (5.6 sones) at max speed
• Convertible ventilation (recirculating or vented)
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Certifications and Approvals
Energy Star Certified
No
Accessories
Optional
• Recirculation Kit(for non-vented installations only): Order part number W10349327
• Replacement Charcoal Filters(for non-vented installations only): Order part number W10412939
• Chimney Extension Kit (Black Stainless Steel): Order part number EXTKIT18HV6" (15.2 cm)
• Makeup Air Kit(consult local building code): Order part number W10446915
• Replacement Charcoal Filters(for non-vented installations only): Order part number W10412939
• Chimney Extension Kit (Black Stainless Steel): Order part number EXTKIT18HV6" (15.2 cm)
• Makeup Air Kit(consult local building code): Order part number W10446915
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
28.87 inch(es) / 73.34 cm
Depth
20 inch(es) / 50.8 cm
Additional Dimensions
• Ceiling height: (Vented, Electric cooking surface) 7' 5" (2.26 m) - 9' 2" (2.79 m)
• Ceiling height: (Vented, Gas cooking surface) 7' 8" (2.34 m) - 9' 2" (2.79 m)
• Ceiling height: (Non-Vented, Electric cooking surface) 7' 5" (2.26 m) - 9' 2" (2.79 m)
• Ceiling height: (Non-Vented, Gas cooking surface) 7' 8" (2.34 m) - 9' 2" (2.79 m)
• Ceiling height: (Vented, Gas cooking surface) 7' 8" (2.34 m) - 9' 2" (2.79 m)
• Ceiling height: (Non-Vented, Electric cooking surface) 7' 5" (2.26 m) - 9' 2" (2.79 m)
• Ceiling height: (Non-Vented, Gas cooking surface) 7' 8" (2.34 m) - 9' 2" (2.79 m)
Shipping Dimensions
Width
41 inch(es) / 104.14 cm
Height
26 inch(es) / 66.04 cm
Depth
23.5 inch(es) / 59.69 cm
Weight
60.01 lb(s) / 27.22 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049466859
