DESCRIPTION
×Introducing Maytag's 30-inch gas range, equipped to handle all your kitchen tasks with ease. Enjoy innovative cooking modes like No-Preheat Air Fry and Air Baking, while freeing up valuable counter space. With an 18,000 BTU Power™ Burner, achieve rapid searing and boiling.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Center Front Element-Burner Power: 10000 BTU
• Center Front Element-Burner Type: Oval Burner
• Center Rear Element-Burner Power: 8,000 BTU
• Center Rear Element-Burner Type: Oval Burner
• Left Front Element-Burner Power: 12000 BTU
• Left Front Element-Burner Type: Griddle
• Left Rear Element-Burner Power: 12,000 BTU
• Left Rear Element-Burner Type: Griddle
• Right Front Element-Burner Power: 18,000 BTU
• Right Front Element-Burner Type: Power
• Right Rear Element-Burner Power: 5000 BTU
• Right Rear Element-Burner Type: Simmer
• Number of Grates: 2
• Center Front Element-Burner Type: Oval Burner
• Center Rear Element-Burner Power: 8,000 BTU
• Center Rear Element-Burner Type: Oval Burner
• Left Front Element-Burner Power: 12000 BTU
• Left Front Element-Burner Type: Griddle
• Left Rear Element-Burner Power: 12,000 BTU
• Left Rear Element-Burner Type: Griddle
• Right Front Element-Burner Power: 18,000 BTU
• Right Front Element-Burner Type: Power
• Right Rear Element-Burner Power: 5000 BTU
• Right Rear Element-Burner Type: Simmer
• Number of Grates: 2
Burners
Sealed
Oven
Capacity (cu. ft.)
5.0 cu. ft.
Number of Ovens
Single
Programs
• Audible Signal
• Bake
• Broil
• Cancel/Off
• Clock
• Control Lock
• Cook Time Indicator
• Delay Start
• Sabbath Mode
• Start Time
• Stop Time
• Timer
• Bake
• Broil
• Cancel/Off
• Clock
• Control Lock
• Cook Time Indicator
• Delay Start
• Sabbath Mode
• Start Time
• Stop Time
• Timer
Features
Air Fry
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Oven Automatic Shut-Off
• Power On Indicator Light
• Power Outage Compatible: No
• Temperature Probe: No
• Display Color: Blue
• Electronic Display Type: LED
Cooktop Details:
• Auto Re-ignition: No
• Cooktop Control Knob Color: Stainless Steel
• Cooktop Control Knob Type: Plastic
• Cooktop Control Location: Backguard
• Cooktop Control Type: Knobs
• Cooktop Surface Color: Black
• Cooktop Surface Material: Porcelain Coated Steel
• Griddle Included: Optional Accessory
• Heating Element On Indicator Light: No
• Hot Surface Indicator Light: No
• Ignition Type: Direct Spark Ignition
• Grate Details: Continuous, Matte Finish, Porcelain Coated Steel Grates
Oven Cavity Details:
• Automatic Convection Conversion Temperature Adjust: No
• Bake Element Power: 16,500 BTU
• Broiler Element Power: 1300W
• Broiler Location: Top Center
• Convection Element Type: Fan
• Convection Functions: Bake, Broil
• Door Removable
• Hidden Bake Element
• Interior Color: Grey
• Number of Oven Lights: 1
• Number of Oven Racks: 2
• Number of Rack Guides: 5
• Oven Cleaning Type: Self-Cleaning
• Oven Cooking System: Thermal
• Oven Light Switch Location: Oven Control
• Oven Light Type: Incandescent
• Oven Rack Type: 2 Standard
• Temperature Probe: No
• Temperature Sensor: No
Exterior Details:
• Door Type: Glass
• Handle Color: Stainless Steel
• Handle Material: Metal
• Handle Type: Reach Through Handle
• Knob Color: Stainless Steel
• Knob Type: Plastic
• Oven Control Knob Type: N/A
• Oven Control Location: Backguard
• Oven Control Type: Electronic Touch
• Oven Window Size: Extra Large
• Power On Indicator Light
• Power Outage Compatible: No
• Temperature Probe: No
• Display Color: Blue
• Electronic Display Type: LED
Cooktop Details:
• Auto Re-ignition: No
• Cooktop Control Knob Color: Stainless Steel
• Cooktop Control Knob Type: Plastic
• Cooktop Control Location: Backguard
• Cooktop Control Type: Knobs
• Cooktop Surface Color: Black
• Cooktop Surface Material: Porcelain Coated Steel
• Griddle Included: Optional Accessory
• Heating Element On Indicator Light: No
• Hot Surface Indicator Light: No
• Ignition Type: Direct Spark Ignition
• Grate Details: Continuous, Matte Finish, Porcelain Coated Steel Grates
Oven Cavity Details:
• Automatic Convection Conversion Temperature Adjust: No
• Bake Element Power: 16,500 BTU
• Broiler Element Power: 1300W
• Broiler Location: Top Center
• Convection Element Type: Fan
• Convection Functions: Bake, Broil
• Door Removable
• Hidden Bake Element
• Interior Color: Grey
• Number of Oven Lights: 1
• Number of Oven Racks: 2
• Number of Rack Guides: 5
• Oven Cleaning Type: Self-Cleaning
• Oven Cooking System: Thermal
• Oven Light Switch Location: Oven Control
• Oven Light Type: Incandescent
• Oven Rack Type: 2 Standard
• Temperature Probe: No
• Temperature Sensor: No
Exterior Details:
• Door Type: Glass
• Handle Color: Stainless Steel
• Handle Material: Metal
• Handle Type: Reach Through Handle
• Knob Color: Stainless Steel
• Knob Type: Plastic
• Oven Control Knob Type: N/A
• Oven Control Location: Backguard
• Oven Control Type: Electronic Touch
• Oven Window Size: Extra Large
Electrical Information
Information
• Amps: 15
• Hz: 60
• Power Cord Included
• Volts: 120
• Watts: 1
• Hz: 60
• Power Cord Included
• Volts: 120
• Watts: 1
Certifications and Approvals
Sabbath/Star-K
Yes
Information
• UL
• CUL
• Star K Certified: Kosher Consumer Friendly
• CUL
• Star K Certified: Kosher Consumer Friendly
Accessories
Included
LP Convertible: Yes - Kit Included
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.87 cm
Weight
178.99 lb(s) / 81.19 kg
Additional Dimensions
• Cutout Depth: 24 in
• Cutout Height: 36 in
• Cutout Width: 30 in
• Depth: 28 in
• Depth Closed Excluding Handles: 25-313/1000 in
• Depth Closed Including Handles: 28 in
• Depth With Door Open 90 Degree: 46-86/125 in
• Height: 47-7/8 in
• Maximum Height: 47-7/8 in
• Minimum Height: 46-1/2 in
• Oven Interior Depth: 19 in
• Oven Interior Height: 18-5/8 in
• Oven Interior Width: 24-1/4 in
• Cutout Height: 36 in
• Cutout Width: 30 in
• Depth: 28 in
• Depth Closed Excluding Handles: 25-313/1000 in
• Depth Closed Including Handles: 28 in
• Depth With Door Open 90 Degree: 46-86/125 in
• Height: 47-7/8 in
• Maximum Height: 47-7/8 in
• Minimum Height: 46-1/2 in
• Oven Interior Depth: 19 in
• Oven Interior Height: 18-5/8 in
• Oven Interior Width: 24-1/4 in
Shipping Dimensions
Height
49 inch(es) / 124.46 cm
Depth
29 inch(es) / 73.66 cm
Weight
195 lb(s) / 88.45 kg
UPC
UPC#
883049684024
