DESCRIPTION
×Enjoy a range of possibilities with our most powerful KitchenAid 30-inch Gas Range available. A WiFi-enabled Smart Appliance featuring Convection Cooking Modes that help you get consistent results with optimal temperatures. A spacious 5.0 Cu. Ft. Capacity and optimized oven system design with Rapid Preheat gets your oven to 350°F in under 8 minutes*. Keep your oven clean with two distinct cleaning cycles: the Steam Clean Cycle, perfect for quick, routine maintenance, and the high-temperature Self-Clean Cycle for a deeper clean. *Using Rapid Preheat to 350 degrees when cooktop is not in use.
SPECIFICATIONS
×
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
PrintShield™ Stainless Steel
Appliance Care
Steam Clean
Cooktop
Burners/Elements
5
Burners/Elements Output
• Right Rear Element Burner Power: 5000 BTU
• Right Front Element Burner Power: 18000 BTU
• Left Rear Element Burner Power: 10000 BTU
• Center Rear Element Burner Power: 12000 BTU
• Right Front Element Burner Power: 18000 BTU
• Left Rear Element Burner Power: 10000 BTU
• Center Rear Element Burner Power: 12000 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
5.0 cu. ft.
Number of Ovens
Single
Features
Technologies
• Works With: Amazon Alexa; Android; Google Assistant; Nest; iOS
• Connectivity: App; Bluetooth; Remote Access; Voice Controlled; WiFi
• True Convection Technology
• Connectivity: App; Bluetooth; Remote Access; Voice Controlled; WiFi
• True Convection Technology
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Wi-Fi
Yes
Additional Information
• Direct Spark Ignition
• Grate Details: Dishwasher Safe; Matte Finish; Porcelain Coated Steel Grates
• Broiler Element Power: 1300 W Electric Broil
• Number Of Rack Guides: 5
• Number Of Oven Racks: 2
• Number Of Oven Lights: 1
• Interior Color: Blue
• Hidden Bake Element: Hidden
• Cooktop Surface Material: Porcelain Coated Steel
• Broiler Location: Top Center
• Oven Control Knob Color: Stainless Steel
• Bake Element Power: 16,500 BTU
• Rack Guide Type: Embossed
• Oven Rack Type: 2 Standard
• Oven Light Type: Halogen
• Door: Removable
• Total Gas Btus Oven: 16,500
• Total Gas Btus Cooktop: 63,000
• Power Outage Compatible
• Grate Details: Dishwasher Safe; Matte Finish; Porcelain Coated Steel Grates
• Broiler Element Power: 1300 W Electric Broil
• Number Of Rack Guides: 5
• Number Of Oven Racks: 2
• Number Of Oven Lights: 1
• Interior Color: Blue
• Hidden Bake Element: Hidden
• Cooktop Surface Material: Porcelain Coated Steel
• Broiler Location: Top Center
• Oven Control Knob Color: Stainless Steel
• Bake Element Power: 16,500 BTU
• Rack Guide Type: Embossed
• Oven Rack Type: 2 Standard
• Oven Light Type: Halogen
• Door: Removable
• Total Gas Btus Oven: 16,500
• Total Gas Btus Cooktop: 63,000
• Power Outage Compatible
Drawer Features
Storage
Yes
Electrical Information
Information
• 120 V
• 60 Hz
• 1400 W
• 15 A
• 60 Hz
• 1400 W
• 15 A
Certifications and Approvals
Sabbath/Star-K
Yes
Information
CUL, UL
Accessories
Optional
4396096RB, W11692811
Dimensions
Class Width
30"
Width
29.9 inch(es) / 75.95 cm
Height
46.5 inch(es) / 118.11 cm
Depth (Without Handles)
24.5 inch(es) / 62.23 cm
Weight
198.99 lb(s) / 90.26 kg
Additional Dimensions
• Depth Closed Excluding Handles: 26.5"
• Depth Closed Including Handles: 28.1"
• Depth With Door Open 90°: 46.8"
• Maximum Height: 52.0"
• Minimum Height: 46.5"
• Cutout Depth: 24.0"
• Cutout Height: 36.0"
• Cutout Width: 30.0"
• Depth Closed Including Handles: 28.1"
• Depth With Door Open 90°: 46.8"
• Maximum Height: 52.0"
• Minimum Height: 46.5"
• Cutout Depth: 24.0"
• Cutout Height: 36.0"
• Cutout Width: 30.0"
Shipping Dimensions
Width
32 inch(es) / 81.28 cm
Height
49 inch(es) / 124.46 cm
Depth
29 inch(es) / 73.66 cm
Weight
214.99 lb(s) / 97.52 kg
UPC
UPC#
883049947358
