Features
Specifications
General
Series Name
Oblivion
Color
Black
Manufacturer Color
Black
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Center Rear Element: 3200/2300W
• Left Front Element: 4500/3000/1500W
• Left Rear Element: 1300W
• Right Rear Element: 1300W
• Left Front Element: 4500/3000/1500W
• Left Rear Element: 1300W
• Right Rear Element: 1300W
Burner/Element Size
• Center Rear Element: 10"/6"
• Left Front Element: 12"/9"/6"
• Left Rear Element: 6"
• Right Rear Element: 6"
• Left Front Element: 12"/9"/6"
• Left Rear Element: 6"
• Right Rear Element: 6"
Elements
Smoothtop
Surface Features
• Design Expression: Oblivian Glass
• Cooktop Surface Material: Glass
• Cooktop Surface Material: Glass
Features
Technologies
• Keep Warm™ Function on All Elements
• Dual-Choice™ Element
• Triple-Choice™ Element
• Dual-Choice™ Element
• Triple-Choice™ Element
Control Lock
Yes
Digital Display
Yes
Additional Information
• Control Type: Electronic Touch
• Heating Element On Indicator Light
• Digital Display
• Hot Surface Indicator Light
• Installs Over Built-In Oven
• Combinations with Oven: JJW2427,JJW2430,JJW3430
• Heating Element On Indicator Light
• Digital Display
• Hot Surface Indicator Light
• Installs Over Built-In Oven
• Combinations with Oven: JJW2427,JJW2430,JJW3430
Electrical Information
Information
• Annual Energy Usage [kWh]: 258
• Amps: 40
• Volts: 240/208
• Hz: 60
• Amps: 40
• Volts: 240/208
• Hz: 60
Certifications and Approvals
ADA Compliant
Yes
Information
UL listed
Accessories
Optional
Power Cord
Dimensions
Class Width
30"
Width
30.81 inch(es) / 78.26 cm
Height
5.25 inch(es) / 13.34 cm
Depth
21.75 inch(es) / 55.25 cm
Weight
41.29 lb(s) / 18.73 kg
Additional Dimensions
• Cutout Depth: 20-3/8"
• Cutout Width: 29-1/16"
• Cutout Width: 29-1/16"
Shipping Dimensions
Width
35 inch(es) / 88.9 cm
Height
9.25 inch(es) / 23.5 cm
Depth
25 inch(es) / 63.5 cm
Weight
46.01 lb(s) / 20.87 kg
UPC
UPC#
883049592398
