DESCRIPTION
×The Frigidaire Gallery 36" Induction Cooktop, features our premium MatteGuard™ Surface that reduces visible scratching by 5X, helping your cooktop maintain a beautiful, like-new finish over time. Experience the speed of induction, with a powerful 3,600-Watt PowerPlus(R) Burner that boils water 50% faster than gas cooktops. The easy-to-use integrated touchcontrol panel offers a sleek and seamless design and makes cooking and cleaning easier. And get peace of mind that this cooktop will fit your existing cutout with our Frigidaire Fit Promise.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Right Front Element: 2,300 / 3,600 Watts (Boost)
• Right Rear Element: 1,450 / 2,500 Watts (Boost)
• Left Front Element: 1,800 / 2,600 Watts (Boost)
• Left Rear Element: 1,800 / 2,600 Watts (Boost)
• Center Element: 2,300 / 3,600 Watts (Boost)
• Right Rear Element: 1,450 / 2,500 Watts (Boost)
• Left Front Element: 1,800 / 2,600 Watts (Boost)
• Left Rear Element: 1,800 / 2,600 Watts (Boost)
• Center Element: 2,300 / 3,600 Watts (Boost)
Burner/Element Size
• Right Front Element Size: 8"
• Right Rear Element Size: 6"
• Left Front Element Size: 7"
• Left Rear Element Size: 7"
• Center Element Size: 8"
• Right Rear Element Size: 6"
• Left Front Element Size: 7"
• Left Rear Element Size: 7"
• Center Element Size: 8"
Elements
Smoothtop
Features
Technologies
MatteGuard™
Control Lock
Yes
Digital Display
Yes
Additional Information
• Kitchen Timer
• On / Off (for each element)
• TempLock
• Cooking Zone Power Level Slide
• Serve Warm
• Auto Pan Detect
• Bridge Element Location: Left
• Cooking Surface Type: Smooth - MatteGuard™
• Hot-Surface Indicator Light
• Bridge On Indicator Light
• Control Location: Front
• Display Interface Color: Red
• Display Type: Capacitive Touch
• On / Off (for each element)
• TempLock
• Cooking Zone Power Level Slide
• Serve Warm
• Auto Pan Detect
• Bridge Element Location: Left
• Cooking Surface Type: Smooth - MatteGuard™
• Hot-Surface Indicator Light
• Bridge On Indicator Light
• Control Location: Front
• Display Interface Color: Red
• Display Type: Capacitive Touch
Electrical Information
Information
• Voltage: 240 V
• Connected Load @ 240V: 9.6 kW
• Minimum Circuit Required: 40 Amps
• Connected Load @ 240V: 9.6 kW
• Minimum Circuit Required: 40 Amps
Certifications and Approvals
ADA Compliant
Yes
Information
• Energy Star Certified
• cUL Listed
• RoHS
• UL Listed
• cUL Listed
• RoHS
• UL Listed
Dimensions
Class Width
36"
Width
36.75 inch(es) / 93.35 cm
Height
2.87 inch(es) / 7.30 cm
Depth
21.37 inch(es) / 54.29 cm
Weight
47 lb(s) / 21.32 kg
Additional Dimensions
• Cutout Height: 3 5/8"
• Minimum Cutout Width: 33 7/8"
• Minimum Cutout Depth: 19 1/8"
• Maximum Cutout Width: 36 1/8"
• Maximum Cutout Depth: 20 1/2"
• Minimum Cutout Width: 33 7/8"
• Minimum Cutout Depth: 19 1/8"
• Maximum Cutout Width: 36 1/8"
• Maximum Cutout Depth: 20 1/2"
Warranty
Warranty
1 Year Parts and Labor
UPC
UPC#
810143401486
