DESCRIPTION
×Frigidaire 30-inch freestanding electric range features 5 cooktop elements, Even Baking technology, SpaceWise® dual expandable element and a total oven capacity of 5.3 cu. ft.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Fuel Type
Electric
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Right Front Element: 3000 Watts
• Right Rear Element: 1200 Watts
• Left Front Element (Small): 1400 Watts
• Left Front Element (Large): 3000 Watts
• Left Rear Element: 1200 Watts
• Center Rear Element: 100 Watts
• Right Rear Element: 1200 Watts
• Left Front Element (Small): 1400 Watts
• Left Front Element (Large): 3000 Watts
• Left Rear Element: 1200 Watts
• Center Rear Element: 100 Watts
Burner/Element Size
• Right Front Element Size: 9"
• Right Rear Element Size: 6"
• Left Front Element Size (Small): 6"
• Left Front Element Size (Large): 9"
• Left Rear Element Size: 6"
• Right Rear Element Size: 6"
• Left Front Element Size (Small): 6"
• Left Front Element Size (Large): 9"
• Left Rear Element Size: 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
5.3 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Preheat
• Broil
• Preheat
Features
Technologies
• Even Baking Technology
• SpaceWise® Dual Expandable Element
• SpaceWise® Dual Expandable Element
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Hot-Surface Indicator Light
• Element On Indicator Light
• Kitchen Timer
• Bake Element: 2600 Watts
• Bake Element Pass: 4
• Bake Element Type: Raised
• Broil Element: 3000 Watts
• Broil Element Pass: 4
• 6 Rack Positions
• Oven Interior Color: Midnight Black
• Oven Light Type: Halogen
• Adjustable Leveling Legs
• Element On Indicator Light
• Kitchen Timer
• Bake Element: 2600 Watts
• Bake Element Pass: 4
• Bake Element Type: Raised
• Broil Element: 3000 Watts
• Broil Element Pass: 4
• 6 Rack Positions
• Oven Interior Color: Midnight Black
• Oven Light Type: Halogen
• Adjustable Leveling Legs
Drawer Features
Storage
Yes
Electrical Information
Information
• Connected Load @ 240V: 12 kW
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
Certifications and Approvals
Information
UL
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
46.75 inch(es) / 118.75 cm
Depth (Without Handles)
26 inch(es) / 66.04 cm
Depth (Including Handles)
28.5 inch(es) / 72.39 cm
Additional Dimensions
• Depth With Door 90° Open: 47 5/16"
• Maximum Height: 47 3/4"
• Oven Interior Height: 8 1/8"
• Oven Interior Width: 25 3/16"
• Oven Interior Depth: 19 7/8"
• Maximum Height: 47 3/4"
• Oven Interior Height: 8 1/8"
• Oven Interior Width: 25 3/16"
• Oven Interior Depth: 19 7/8"
Warranty
Warranty
1 Year Parts and Labor
UPC
UPC#
12505514609
