DESCRIPTION
×The Frigidaire 30" Front Control Electric Range features Air Fry, so you can make healthier, family-sized air fry meals, right in your oven. Includes a five-element cooktop that is designed to handle all of your cooking needs, including a powerful 3,200-Watt Quick Boil Element. . Cleaning your oven interior is now more convenient with our 30-minute steam clean. Enjoy the flexibility of our 2-in-1 Dual Expandable element that can accommodate both small and larger pot sizes. Also features a sleek, modern edge-to-edge glass design that will look great in any kitchen.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Fuel Type
Electric
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
Steam Clean
Cooktop
Burners/Elements
5
Burners/Elements Output
• Right Front Element: 3,200 Watts
• Right Rear Element: 1,200 Watts
• Left Rear Element: 1,200 Watts
• Center Rear Element: 100 Watts
• Left Front Element (Large): 3,000 Watts
• Left Front Element (Small) 1,400 Watts
• Right Rear Element: 1,200 Watts
• Left Rear Element: 1,200 Watts
• Center Rear Element: 100 Watts
• Left Front Element (Large): 3,000 Watts
• Left Front Element (Small) 1,400 Watts
Burner/Element Size
• Right Front Element: 9"
• Right Rear Element: 6"
• Left Rear Element: 6"
• Left Front Element (Large): 9"
• Left Front Element (Small): 6"
• Right Rear Element: 6"
• Left Rear Element: 6"
• Left Front Element (Large): 9"
• Left Front Element (Small): 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
5.3 cu. ft.
Number of Ovens
Single
Programs
• Air Fry
• Bake
• Broil
• Clock
• Convection Bake
• Keep Warm
• Lockout
• Off
• Oven Light
• Preheat
• Set Clock
• Start
• Steam Clean
• Temperature Display
• Timer On / Off
• Up / Down Arrow
• Warm Zone
• Bake
• Broil
• Clock
• Convection Bake
• Keep Warm
• Lockout
• Off
• Oven Light
• Preheat
• Set Clock
• Start
• Steam Clean
• Temperature Display
• Timer On / Off
• Up / Down Arrow
• Warm Zone
Features
Technologies
Convection Technology
Air Fry
Yes
Control Lock
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Bake Element: 2500 Watts
• Bake Element Pass: 8
• Bake Element Type: Hidden
• Bake System
• Broil Element: 3500 Watts
• Broil Element Pass: 6
• Broil System
• Convection Type: Fan
• Number of Convection: Fans 1
• Number of Rack Positions: 6
• Oven Interior Color: Midnight Black
• Oven Light Quantity: 1
• Oven Light Type: Halogen
• Oven Light Watts: 40 Watts
• Rack Position Type: Embossed
• Rack Type 1: Flat
• Rack Type 1 Quantity: 2
• Adjustable Leveling Legs
• Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
• Program Fahrenheit or Celsius
• Silent Control Panel
• Element On Indicator Light
• Hot-Surface Indicator Light
• Keep Warm Zone Light
• Control Location: Front
• Display Interface Color: White
• Display Light Color: White
• Display Type: LED
• Bake Element Pass: 8
• Bake Element Type: Hidden
• Bake System
• Broil Element: 3500 Watts
• Broil Element Pass: 6
• Broil System
• Convection Type: Fan
• Number of Convection: Fans 1
• Number of Rack Positions: 6
• Oven Interior Color: Midnight Black
• Oven Light Quantity: 1
• Oven Light Type: Halogen
• Oven Light Watts: 40 Watts
• Rack Position Type: Embossed
• Rack Type 1: Flat
• Rack Type 1 Quantity: 2
• Adjustable Leveling Legs
• Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
• Program Fahrenheit or Celsius
• Silent Control Panel
• Element On Indicator Light
• Hot-Surface Indicator Light
• Keep Warm Zone Light
• Control Location: Front
• Display Interface Color: White
• Display Light Color: White
• Display Type: LED
Drawer Features
Storage
Yes
Electrical Information
Information
• Amps @ 120 Volts: 9 Amps
• Amps @ 240 Volts: 12 Amps
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
• Amps @ 240 Volts: 12 Amps
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
Certifications and Approvals
ADA Compliant
Yes
Information
• cUL Listed
• ENERGY STAR Certified
• ENERGY STAR Certified
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
35.63 inch(es) / 90.5 cm
Depth (Without Handles)
26 inch(es) / 66.04 cm
Depth (Including Handles)
28.5 inch(es) / 72.39 cm
Additional Dimensions
• Depth With Door 90° Open: 47 5/16"
• Oven Interior Height: 18 1/8"
• Oven Interior Width: 25 3/16"
• Oven Interior Depth: 19 7/8"
• Maximum Height: 36 5/8"
• Oven Interior Height: 18 1/8"
• Oven Interior Width: 25 3/16"
• Oven Interior Depth: 19 7/8"
• Maximum Height: 36 5/8"
Warranty
Warranty
1 Year Parts and Labor
