DESCRIPTION
×Achieve better baking results with Convection Bake and get faster, more even baking results with the fan convection baking system. This 24" electric range is compact in design and fits perfectly into smaller kitchens. The smooth, glass design of the cooktop seamlessly integrates with your countertop, making it easy to clean.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Fuel Type
Electric
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
4
Burners/Elements Output
• Right Front Element Burner: 1,200 Watts
• Right Rear Element Burner: 1,800 Watts
• Left Rear Element Burner: 1,200 Watts
• Left Front Element Burner: 800/1,800 Watts
• Right Rear Element Burner: 1,800 Watts
• Left Rear Element Burner: 1,200 Watts
• Left Front Element Burner: 800/1,800 Watts
Burner/Element Size
• Right Front Element Burner Size: 6"
• Right Rear Element Burner Size: 7"
• Left Rear Element Burner Size: 6"
• Left Front Element Burner Size 7"
• Right Rear Element Burner Size: 7"
• Left Rear Element Burner Size: 6"
• Left Front Element Burner Size 7"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
1.9 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Convection Bake
• Convection Broil
• Broil
• Convection Bake
• Convection Broil
Features
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Cooking Surface Type: Smooth
• Element On Indicator Light
• Hot-Surface Indicator Light
• Keep Warm
• On / Off (for each element)
• Oven Indicator Light
• Oven Light
• Timer On / Off
• Up / Down Arrow
• Bake Element Type: Hidden
• Bake Element Pass: 4
• Bake Element: 1,000 Watts
• Broil Element Pass: 4
• Broil Element: 1,800 Watts
• Convection Type: Fan
• Rack Position Type: Embossed
• Number of Rack Positions: 4
• Rack Type 1: Flat
• Rack Type 1 Quantity: 2
• Oven Interior Color: Midnight Black
• Oven Light Type: Halogen
• Oven Light Quantity: 1
• Oven Light Watts: 25 Watts
• Element On Indicator Light
• Hot-Surface Indicator Light
• Keep Warm
• On / Off (for each element)
• Oven Indicator Light
• Oven Light
• Timer On / Off
• Up / Down Arrow
• Bake Element Type: Hidden
• Bake Element Pass: 4
• Bake Element: 1,000 Watts
• Broil Element Pass: 4
• Broil Element: 1,800 Watts
• Convection Type: Fan
• Rack Position Type: Embossed
• Number of Rack Positions: 4
• Rack Type 1: Flat
• Rack Type 1 Quantity: 2
• Oven Interior Color: Midnight Black
• Oven Light Type: Halogen
• Oven Light Quantity: 1
• Oven Light Watts: 25 Watts
Drawer Features
Storage
Yes
Electrical Information
Information
• Connected Load @ 240V: 8 kW
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
Certifications and Approvals
Information
CSA
Accessories
Included
Power Cord
Dimensions
Class Width
24"
Width
23.5 inch(es) / 59.69 cm
Height
35.87 inch(es) / 91.12 cm
Depth (Without Handles)
41.5 inch(es) / 105.41 cm
Additional Dimensions
• Depth With Door 90° Open: 41 1/2"
• Oven Interior Height: 12 7/8"
• Oven Interior Width: 16 1/8"
• Oven Interior Depth: 16 3/8"
• Maximum Height: 36 7/8"
• Oven Interior Height: 12 7/8"
• Oven Interior Width: 16 1/8"
• Oven Interior Depth: 16 3/8"
• Maximum Height: 36 7/8"
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
12505566493
