DESCRIPTION
×This 36-inch Bosch 500 Series induction cooktop features SpeedBoost®, 5 elements, 17 power levels for each cooking zone, and is Wi-Fi Enabled. The 500 Series induction cooktop is sleek in design and offers quick and even cooking results.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Series Name
500 Series
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Front Left: 1,800 W
• Front Left (in boost): 3,100 W
• Back Left: 1,800 W
• Back Left (in boost): 3,100 W
• Back Right: 1,400 W
• Back Right (in boost): 2,200 W
• Front Right: 2,200 W
• Front Right (in boost): 3,600 W
• Center: 2,200 / 2,600 / 3,300 W
• Center (in boost): 3,600 / 3,600 / 3,600 W
• Front Left (in boost): 3,100 W
• Back Left: 1,800 W
• Back Left (in boost): 3,100 W
• Back Right: 1,400 W
• Back Right (in boost): 2,200 W
• Front Right: 2,200 W
• Front Right (in boost): 3,600 W
• Center: 2,200 / 2,600 / 3,300 W
• Center (in boost): 3,600 / 3,600 / 3,600 W
Burner/Element Size
• Front Left: 6"
• Back Left: 9"
• Back Right: 11"
• Front Right: 6"
• Center: 9" / 11" /13" Triple-ring
• Back Left: 9"
• Back Right: 11"
• Front Right: 6"
• Center: 9" / 11" /13" Triple-ring
Elements
Smoothtop
Features
Technologies
• Induction Technology
• SpeedBoost®
• SpeedBoost®
Wi-Fi
Yes
Control Lock
Yes
Digital Display
Yes
Additional Information
• 17 power levels for each cooking zone
• SpeedBoost® - adds even more power to speed up the cooking process
• Quick Start: start straight away and select the desired cooking level.
• ReStart: if something boils over, the cooktop automatically turns itself off and saves the last selected setting
• Favorite button - one touch for your two most used cooking settings
• Automatic time limitation - will shut off your cooktop if the cooking zone has been in use for a long period of time without any changes
• SpeedBoost® - adds even more power to speed up the cooking process
• Quick Start: start straight away and select the desired cooking level.
• ReStart: if something boils over, the cooktop automatically turns itself off and saves the last selected setting
• Favorite button - one touch for your two most used cooking settings
• Automatic time limitation - will shut off your cooktop if the cooking zone has been in use for a long period of time without any changes
Electrical Information
Information
• 8,320 / 9,600 W
• 40 A
• 60 Hz
• 208 -240 V
• 40 A
• 60 Hz
• 208 -240 V
Certifications and Approvals
ADA Compliant
Yes
Information
Dekra US
Dimensions
Class Width
36"
Width
37 inch(es) / 93.98 cm
Height
4.25 inch(es) / 10.8 cm
Depth
21.25 inch(es) / 53.98 cm
Weight
50 lb(s) / 22.68 kg
Additional Dimensions
• Required cutout size (HxWxD): 4 1/8" x 34 7/8" x 20 1/4"
• Minimum distance from counter front: 2 1/4"
• Minimum distance from rear wall: 2"
• Minimum distance from counter front: 2 1/4"
• Minimum distance from rear wall: 2"
